Mitsubishi
Mitsubishi S6R-A2PTAW
S6R Series
Mitsubishi S6R-A2PTAW 24.510L L6 constant-speed diesel engine for generator applications. Official MHI output without fan - 50 Hz: prime 541 kWm at 1500 rpm, standby 595 kWm at 1500 rpm. Emissions: Unregulated (prime); U.S. EPA Tier 2 (standby).
- Standby Power · 50 Hz
- 707 kVA
- Electrical Output
- 566 kWe
- Cylinders
- L6
- Displacement
- 24.51 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 541 | 513.6 | 642 |
| Standby Power | 595 | 565.6 | 707 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Mitsubishi S6R-A2PTAW generator set context
The Mitsubishi S6R-A2PTAW is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 707 kVA / 566 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Mitsubishi |
| Model | S6R-A2PTAW |
| Series | S6R Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 24.51 L |
| Dry Weight | 2705 kg |
| Dimensions (L×W×H) | 1872 × 1084 × 1498 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Mitsubishi S6R-A2PTAW?
The Mitsubishi S6R-A2PTAW is rated at 707 kVA standby / 642 kVA prime at 50 Hz (1,500 rpm).
Does the S6R-A2PTAW run at 50 Hz or 60 Hz?
The Mitsubishi S6R-A2PTAW is rated for 50 Hz (1,500 rpm).
What fuel does the Mitsubishi S6R-A2PTAW use?
The Mitsubishi S6R-A2PTAW is a diesel generator-set engine.
What is the displacement and cylinder configuration of the S6R-A2PTAW?
The Mitsubishi S6R-A2PTAW is an inline-6 (6-cylinder) engine with a displacement of 24.51 L.
What emissions standard does the S6R-A2PTAW meet?
The Mitsubishi S6R-A2PTAW is certified to U.S. EPA Tier 2 emissions standards.
Is the Mitsubishi S6R-A2PTAW still in production?
Yes — the Mitsubishi S6R-A2PTAW is a current production model.
Is a datasheet available for the S6R-A2PTAW?
Yes — an official Mitsubishi datasheet for the Mitsubishi S6R-A2PTAW can be downloaded from this page.
Related Engines
Compare Mitsubishi S6R-A2PTAW
Reference
- Canonical page
- /engines/mitsubishi-s6r-a2ptaw
- Last database update
- 2026-07-23
- Manufacturer files
- 1 datasheet linked
