MTU
MTU 12V1600 G91S
Series 1600 Gx1
MTU 12V1600 G91S 22.4 L V12 diesel/HVO gendrive engine with a 126 x 150 mm bore and stroke, rated at 996 kWm gross mechanical power at 1800 RPM for 60 Hz standby service. MTU lists the Series 1600 Gx1 with an EPA Tier 2 calibration. Electrical kWe and kVA depend on the selected generator package and alternator and are not inferred here.
- Electrical Output
- 996 kW
- Cylinders
- V12
- Displacement
- 22.444 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Standby Power | 996 | — | — |
MTU 12V1600 G91S generator set context
The MTU 12V1600 G91S is listed here as a diesel/hvo generator-drive engine for 60 Hz generator sets, with a headline 996 kW / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MTU |
| Model | 12V1600 G91S |
| Series | Series 1600 Gx1 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 22.444 L |
| Fuel Type | Diesel/HVO |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 2 |
| Certifications | U.S. EPA Tier 2 |
| Country of Origin | Germany |
| Year Introduced | 2024 |
Frequently asked questions
What is the power output of the MTU 12V1600 G91S?
The MTU 12V1600 G91S is rated at 1,245 kVA standby at 60 Hz (1,800 rpm).
Does the 12V1600 G91S run at 50 Hz or 60 Hz?
The MTU 12V1600 G91S is rated for 60 Hz (1,800 rpm).
What fuel does the MTU 12V1600 G91S use?
The MTU 12V1600 G91S is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 12V1600 G91S?
The MTU 12V1600 G91S is a V12 (12-cylinder) engine with a displacement of 22.444 L.
What emissions standard does the 12V1600 G91S meet?
The MTU 12V1600 G91S is certified to U.S. EPA Tier 2 emissions standards.
Is the MTU 12V1600 G91S still in production?
Yes — the MTU 12V1600 G91S is a current production model.
Is a datasheet available for the 12V1600 G91S?
Yes — an official MTU datasheet for the MTU 12V1600 G91S can be downloaded from this page.
Reference
- Canonical page
- /engines/mtu-12v1600g91s
- Last database update
- 2026-07-24
- Manufacturer files
- 1 datasheet linked
