MWM
MWM TCG 3016 V12
TCG 3016
MWM TCG 3016 V12 — 26.3 L V12 spark-ignition gas engine (TCG 3016 series), multi-fuel: natural gas, biogas and sewage/landfill gas. 600 kWe at 1500 rpm / 50 Hz, 600 kWe at 1800 rpm / 60 Hz; NOx ≤ 500 mg/Nm³.
- Prime Power · 50 Hz
- 750 kVA
- Electrical Output
- 600 kWe
- Cylinders
- V12
- Displacement
- 26.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 600 | 750 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 600 | 750 |
Technical Specifications
| Brand | MWM |
| Model | TCG 3016 V12 |
| Series | TCG 3016 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 26.3 L |
| Dry Weight | 7000 kg |
| Dimensions (L×W×H) | 3830 × 1780 × 2150 mm |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
