MWM
MWM TCG 2020 V16
TCG 2020
MWM TCG 2020 V16 — 70.8 L V16 spark-ignition gas engine (TCG 2020 series), multi-fuel: natural gas, biogas and sewage/landfill gas. 1560 kWe at 1500 rpm / 50 Hz; NOx ≤ 500 mg/Nm³.
- Prime Power · 50 Hz
- 1,950 kVA
- Electrical Output
- 1,560 kWe
- Cylinders
- V16
- Displacement
- 70.8 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1560 | 1950 |
Technical Specifications
| Brand | MWM |
| Model | TCG 2020 V16 |
| Series | TCG 2020 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 70.8 L |
| Dry Weight | 13300 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
