MWM
MWM TCG 2020 V12
TCG 2020
MWM TCG 2020 V12 — 53.1 L V12 spark-ignition gas engine (TCG 2020 series), multi-fuel: natural gas, biogas and sewage/landfill gas. 1200 kWe at 1500 rpm / 50 Hz; NOx ≤ 500 mg/Nm³.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-06-08
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 1,500 kVA
- Electrical Output
- 1,200 kWe
- Cylinders
- V12
- Displacement
- 53.1 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 1200 | 1500 |
Ask about MWM TCG 2020 V12
Choose parts / service or sourcing. Your message includes this model and page link.
MWM TCG 2020 V12 overhaul & repair parts
Already running a MWM TCG 2020 V12? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with TCG 2020 V12 and your selected categories included. Attach your photos there.
MWM TCG 2020 V12 generator set context
The MWM TCG 2020 V12 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 1,500 kVA / 1,200 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | MWM |
| Model | TCG 2020 V12 |
| Series | TCG 2020 |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 53.1 L |
| Dry Weight | 11700 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
Frequently asked questions
What is the power output of the MWM TCG 2020 V12?
The MWM TCG 2020 V12 is rated at 1,500 kVA prime at 50 Hz (1,500 rpm).
Does the TCG 2020 V12 run at 50 Hz or 60 Hz?
The MWM TCG 2020 V12 is rated for 50 Hz (1,500 rpm).
What fuel does the MWM TCG 2020 V12 use?
The MWM TCG 2020 V12 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the TCG 2020 V12?
The MWM TCG 2020 V12 is a V12 (12-cylinder) engine with a displacement of 53.1 L.
What is the catalog status of the MWM TCG 2020 V12?
The MWM TCG 2020 V12 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the TCG 2020 V12?
This page links reference documents for the MWM TCG 2020 V12. Check each document's title, model coverage, revision and rating conditions before using it for selection.
