Perkins
Perkins 2806A-E18TTAG6
2800 Series
The Perkins 2806A-E18TTAG6 is a 18-litre inline-6 diesel engine for generator sets, rated at 895 kVA / 716 kWe standby power at 1,800 RPM (60 Hz). It is a liquid-cooled engine built in United Kingdom.
Overhaul & repair parts- Supporting documents
- 2 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 60 Hz
- 895 kVA
- Electrical Output
- 716 kWe
- Cylinders
- L6
- Displacement
- 18 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 722.2 | 650 | 812.5 |
| Standby Power | 795.6 | 716 | 895 |
Ask about Perkins 2806A-E18TTAG6
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 2806A-E18TTAG6 overhaul & repair parts
Already running a Perkins 2806A-E18TTAG6? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 2806A-E18TTAG6 and your selected categories included. Attach your photos there.
Perkins 2806A-E18TTAG6 generator set context
The Perkins 2806A-E18TTAG6 is listed here as a diesel generator-drive engine for 60 Hz generator sets, with a headline 895 kVA / 716 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 2806A-E18TTAG6 |
| Series | 2800 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 2806A-E18TTAG6?
The Perkins 2806A-E18TTAG6 is rated at 895 kVA standby / 813 kVA prime at 60 Hz (1,800 rpm).
Does the 2806A-E18TTAG6 run at 50 Hz or 60 Hz?
The Perkins 2806A-E18TTAG6 is rated for 60 Hz (1,800 rpm).
What fuel does the Perkins 2806A-E18TTAG6 use?
The Perkins 2806A-E18TTAG6 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 2806A-E18TTAG6?
The Perkins 2806A-E18TTAG6 is an inline-6 (6-cylinder) engine with a displacement of 18 L.
What is the catalog status of the Perkins 2806A-E18TTAG6?
The Perkins 2806A-E18TTAG6 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 2806A-E18TTAG6?
This page links reference documents for the Perkins 2806A-E18TTAG6. Check each document's title, model coverage, revision and rating conditions before using it for selection.
