Perkins
Perkins 2806A-E18TTAG4
2800 Series
The Perkins 2806A-E18TTAG4 is a 18-litre inline-6 diesel engine for generator sets, rated at 780 kVA / 624 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom.
- Standby Power · 50 Hz
- 780 kVA
- Electrical Output
- 624 kWe
- Cylinders
- L6
- Displacement
- 18 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 627.8 | 565 | 706.3 |
| Standby Power | 693.3 | 624 | 780 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 713.3 | 642 | 802.5 |
| Standby Power | 788.9 | 710 | 887.5 |
Technical Specifications
| Brand | Perkins |
| Model | 2806A-E18TTAG4 |
| Series | 2800 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 2806A-E18TTAG4?
The Perkins 2806A-E18TTAG4 is rated at 780 kVA standby / 706 kVA prime at 50 Hz (1,500 rpm); and 888 kVA standby / 803 kVA prime at 60 Hz (1,800 rpm).
Does the 2806A-E18TTAG4 run at 50 Hz or 60 Hz?
The Perkins 2806A-E18TTAG4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 2806A-E18TTAG4 use?
The Perkins 2806A-E18TTAG4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 2806A-E18TTAG4?
The Perkins 2806A-E18TTAG4 is an inline-6 (6-cylinder) engine with a displacement of 18 L.
Is the Perkins 2806A-E18TTAG4 still in production?
Yes — the Perkins 2806A-E18TTAG4 is a current production model.
Is a datasheet available for the 2806A-E18TTAG4?
Yes — an official Perkins datasheet for the Perkins 2806A-E18TTAG4 can be downloaded from this page.
