Perkins
Perkins 2806C-E18TAG1A
2800 Series
The Perkins 2806C-E18TAG1A is a 18-litre inline-6 diesel engine for generator sets, rated at 650 kVA / 520 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in United Kingdom.
Overhaul & repair parts- Supporting documents
- 3 documents · 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 650 kVA
- Electrical Output
- 520 kWe
- Cylinders
- L6
- Displacement
- 18 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 525.6 | 473 | 591.3 |
| Standby Power | 577.8 | 520 | 650 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 555.6 | 500 | 625 |
| Standby Power | 611.1 | 550 | 687.5 |
Ask about Perkins 2806C-E18TAG1A
Choose parts / service or sourcing. Your message includes this model and page link.
Perkins 2806C-E18TAG1A overhaul & repair parts
Already running a Perkins 2806C-E18TAG1A? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 2806C-E18TAG1A and your selected categories included. Attach your photos there.
Perkins 2806C-E18TAG1A generator set context
The Perkins 2806C-E18TAG1A is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 650 kVA / 520 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Perkins |
| Model | 2806C-E18TAG1A |
| Series | 2800 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United Kingdom |
Frequently asked questions
What is the power output of the Perkins 2806C-E18TAG1A?
The Perkins 2806C-E18TAG1A is rated at 650 kVA standby / 591 kVA prime at 50 Hz (1,500 rpm); and 688 kVA standby / 625 kVA prime at 60 Hz (1,800 rpm).
Does the 2806C-E18TAG1A run at 50 Hz or 60 Hz?
The Perkins 2806C-E18TAG1A is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Perkins 2806C-E18TAG1A use?
The Perkins 2806C-E18TAG1A is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 2806C-E18TAG1A?
The Perkins 2806C-E18TAG1A is an inline-6 (6-cylinder) engine with a displacement of 18 L.
What is the catalog status of the Perkins 2806C-E18TAG1A?
The Perkins 2806C-E18TAG1A is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 2806C-E18TAG1A?
This page links reference documents for the Perkins 2806C-E18TAG1A. Check each document's title, model coverage, revision and rating conditions before using it for selection.
