Scania
Scania DC13 505A 300
DC13 Series
Scania DC13 505A 300 13L 6-cylinder diesel engine for generator sets. EU Stage V emissions.
- Prime Power · 50 Hz
- 300 kVA
- Electrical Output
- 240 kWe
- Cylinders
- L6
- Displacement
- 13 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 266.7 | 240 | 300 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 266.7 | 240 | 300 |
Technical Specifications
| Brand | Scania |
| Model | DC13 505A 300 |
| Series | DC13 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Sweden |
Frequently asked questions
What is the power output of the Scania DC13 505A 300?
The Scania DC13 505A 300 is rated at 300 kVA prime at 50 Hz (1,500 rpm); and 300 kVA prime at 60 Hz (1,800 rpm).
Does the DC13 505A 300 run at 50 Hz or 60 Hz?
The Scania DC13 505A 300 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Scania DC13 505A 300 use?
The Scania DC13 505A 300 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DC13 505A 300?
The Scania DC13 505A 300 is an inline-6 (6-cylinder) engine with a displacement of 13 L.
What emissions standard does the DC13 505A 300 meet?
The Scania DC13 505A 300 is certified to Euro Stage V emissions standards.
Is the Scania DC13 505A 300 still in production?
Yes — the Scania DC13 505A 300 is a current production model.
Is a datasheet available for the DC13 505A 300?
Yes — an official Scania datasheet for the Scania DC13 505A 300 can be downloaded from this page.
