Scania
Scania DC13 505A 350
DC13 Series
Scania DC13 505A 350 13L 6-cylinder diesel engine for generator sets. EU Stage V emissions.
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 350 kVA
- Electrical Output
- 280 kWe
- Cylinders
- L6
- Displacement
- 13 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 311.1 | 280 | 350 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 311.1 | 280 | 350 |
Ask about Scania DC13 505A 350
Choose parts / service or sourcing. Your message includes this model and page link.
Scania DC13 505A 350 overhaul & repair parts
Already running a Scania DC13 505A 350? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DC13 505A 350 and your selected categories included. Attach your photos there.
Scania DC13 505A 350 generator set context
The Scania DC13 505A 350 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 350 kVA / 280 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Scania |
| Model | DC13 505A 350 |
| Series | DC13 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Sweden |
Frequently asked questions
What is the power output of the Scania DC13 505A 350?
The Scania DC13 505A 350 is rated at 350 kVA prime at 50 Hz (1,500 rpm); and 350 kVA prime at 60 Hz (1,800 rpm).
Does the DC13 505A 350 run at 50 Hz or 60 Hz?
The Scania DC13 505A 350 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Scania DC13 505A 350 use?
The Scania DC13 505A 350 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DC13 505A 350?
The Scania DC13 505A 350 is an inline-6 (6-cylinder) engine with a displacement of 13 L.
What emissions information is listed for the DC13 505A 350?
This record lists Euro Stage V for the Scania DC13 505A 350. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Scania DC13 505A 350?
The Scania DC13 505A 350 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DC13 505A 350?
This page links reference documents for the Scania DC13 505A 350. Check each document's title, model coverage, revision and rating conditions before using it for selection.
