Scania
Scania DC13 505A 400
DC13 Series
Scania DC13 505A 400 13L 6-cylinder diesel engine for generator sets. EU Stage V emissions.
Chat on WhatsApp about this engine
Opens WhatsApp with Scania DC13 505A 400 and this page link filled in.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Prime Power · 50 Hz
- 400 kVA
- Electrical Output
- 320 kWe
- Cylinders
- L6
- Displacement
- 13 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 355.6 | 320 | 400 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 355.6 | 320 | 400 |
Scania DC13 505A 400 generator set context
The Scania DC13 505A 400 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 400 kVA / 320 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Scania |
| Model | DC13 505A 400 |
| Series | DC13 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 13 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | Sweden |
Frequently asked questions
What is the power output of the Scania DC13 505A 400?
The Scania DC13 505A 400 is rated at 400 kVA prime at 50 Hz (1,500 rpm); and 400 kVA prime at 60 Hz (1,800 rpm).
Does the DC13 505A 400 run at 50 Hz or 60 Hz?
The Scania DC13 505A 400 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Scania DC13 505A 400 use?
The Scania DC13 505A 400 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DC13 505A 400?
The Scania DC13 505A 400 is an inline-6 (6-cylinder) engine with a displacement of 13 L.
What emissions standard does the DC13 505A 400 meet?
The Scania DC13 505A 400 is certified to Euro Stage V emissions standards.
Is the Scania DC13 505A 400 still in production?
Yes — the Scania DC13 505A 400 is a current production model.
Is a datasheet available for the DC13 505A 400?
Yes — an official Scania datasheet for the Scania DC13 505A 400 can be downloaded from this page.
