Waukesha
Waukesha VGF18GL/GLD (F18GL/GLD)
VGF
Waukesha VGF18GL/GLD is the remote-radiator generator package using the 18 L F18GL/GLD inline-six natural-gas engine. INNIO publishes 330 kWb continuous engine output at 1800 RPM, with 310 kWe continuous and 315 kWe standby package ratings at 60 Hz.
Overhaul & repair parts- Manufacturer files
- 3 datasheets
- Last updated
- 2026-07-26
- Package route
- gas generator sets
- Standby Power · 60 Hz
- 394 kVA
- Electrical Output
- 315 kWe
- Cylinders
- L6
- Displacement
- 18 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 330 | 310 | 387.5 |
| Standby Power | — | 315 | — |
Ask about Waukesha VGF18GL/GLD (F18GL/GLD)
Choose parts / service or sourcing. Your message includes this model and page link.
Waukesha VGF18GL/GLD (F18GL/GLD) overhaul & repair parts
Already running a Waukesha VGF18GL/GLD (F18GL/GLD)? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with VGF18GL/GLD (F18GL/GLD) and your selected categories included. Attach your photos there.
Waukesha VGF18GL/GLD (F18GL/GLD) generator set context
The Waukesha VGF18GL/GLD (F18GL/GLD) is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 394 kVA / 315 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Waukesha |
| Model | VGF18GL/GLD (F18GL/GLD) |
| Series | VGF |
| Configuration | L6 Turbocharged Intercooled Lean Burn |
| Cylinders | 6 |
| Displacement | 18 L |
| Compression Ratio | 11:1 |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Waukesha VGF18GL/GLD (F18GL/GLD)?
The Waukesha VGF18GL/GLD (F18GL/GLD) is rated at 394 kVA standby / 388 kVA prime at 60 Hz (1,800 rpm).
Does the VGF18GL/GLD (F18GL/GLD) run at 50 Hz or 60 Hz?
The Waukesha VGF18GL/GLD (F18GL/GLD) is rated for 60 Hz (1,800 rpm).
What fuel does the Waukesha VGF18GL/GLD (F18GL/GLD) use?
The Waukesha VGF18GL/GLD (F18GL/GLD) is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the VGF18GL/GLD (F18GL/GLD)?
The Waukesha VGF18GL/GLD (F18GL/GLD) is an inline-6 (6-cylinder) engine with a displacement of 18 L.
What is the catalog status of the Waukesha VGF18GL/GLD (F18GL/GLD)?
The Waukesha VGF18GL/GLD (F18GL/GLD) is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the VGF18GL/GLD (F18GL/GLD)?
This page links reference documents for the Waukesha VGF18GL/GLD (F18GL/GLD). Check each document's title, model coverage, revision and rating conditions before using it for selection.
