Waukesha
Waukesha VGF24SE (H24SE)
VGF
Waukesha VGF24SE is the remote-radiator generator package using the 24 L H24SE inline-eight natural-gas engine. INNIO publishes 400 kWb continuous engine output at 1800 RPM, with 375 kWe continuous and 410 kWe standby package ratings at 60 Hz. INNIO also publishes an EPA-certified H24SE-EPA configuration.
Overhaul & repair parts- Manufacturer files
- 2 datasheets
- Last updated
- 2026-07-26
- Package route
- gas generator sets
- Standby Power · 60 Hz
- 513 kVA
- Electrical Output
- 410 kWe
- Cylinders
- V8
- Displacement
- 24 L
- Rated Speed
- 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 400 | 375 | 468.8 |
| Standby Power | — | 410 | 512.5 |
Ask about Waukesha VGF24SE (H24SE)
Choose parts / service or sourcing. Your message includes this model and page link.
Waukesha VGF24SE (H24SE) overhaul & repair parts
Already running a Waukesha VGF24SE (H24SE)? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with VGF24SE (H24SE) and your selected categories included. Attach your photos there.
Waukesha VGF24SE (H24SE) generator set context
The Waukesha VGF24SE (H24SE) is listed here as a natural gas generator-drive engine for 60 Hz generator sets, with a headline 513 kVA / 410 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Waukesha |
| Model | VGF24SE (H24SE) |
| Series | VGF |
| Configuration | L8 Turbocharged Intercooled |
| Cylinders | 8 |
| Displacement | 24 L |
| Compression Ratio | 8.6:1 |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Stationary |
| Certifications | U.S. EPA Stationary, U.S. EPA NSPS Subpart JJJJ |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Waukesha VGF24SE (H24SE)?
The Waukesha VGF24SE (H24SE) is rated at 513 kVA standby / 469 kVA prime at 60 Hz (1,800 rpm).
Does the VGF24SE (H24SE) run at 50 Hz or 60 Hz?
The Waukesha VGF24SE (H24SE) is rated for 60 Hz (1,800 rpm).
What fuel does the Waukesha VGF24SE (H24SE) use?
The Waukesha VGF24SE (H24SE) is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the VGF24SE (H24SE)?
The Waukesha VGF24SE (H24SE) is a V8 (8-cylinder) engine with a displacement of 24 L.
What emissions information is listed for the VGF24SE (H24SE)?
This record lists U.S. EPA Stationary for the Waukesha VGF24SE (H24SE). Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Waukesha VGF24SE (H24SE)?
The Waukesha VGF24SE (H24SE) is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the VGF24SE (H24SE)?
This page links reference documents for the Waukesha VGF24SE (H24SE). Check each document's title, model coverage, revision and rating conditions before using it for selection.
