Weichai
Weichai WP4.6ND120E310
WP Series
The Weichai WP4.6ND120E310 is a 4.6-litre inline-4 diesel engine for generator sets, rated at 135 kVA / 108 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Get help with this engine
Tell Haifeng whether you already own a Weichai WP4.6ND120E310 engine/generator or need to source this model for a project.
- Manufacturer files
- 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 135 kVA
- Electrical Output
- 108 kWe
- Cylinders
- L4
- Displacement
- 4.6 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 110 | 99 | 123.8 |
| Standby Power | 120 | 108 | 135 |
Weichai WP4.6ND120E310 generator set context
The Weichai WP4.6ND120E310 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 135 kVA / 108 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Weichai |
| Model | WP4.6ND120E310 |
| Series | WP Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.6 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Weichai WP4.6ND120E310?
The Weichai WP4.6ND120E310 is rated at 135 kVA standby / 124 kVA prime at 50 Hz (1,500 rpm).
Does the WP4.6ND120E310 run at 50 Hz or 60 Hz?
The Weichai WP4.6ND120E310 is rated for 50 Hz (1,500 rpm).
What fuel does the Weichai WP4.6ND120E310 use?
The Weichai WP4.6ND120E310 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the WP4.6ND120E310?
The Weichai WP4.6ND120E310 is an inline-4 (4-cylinder) engine with a displacement of 4.6 L.
Is the Weichai WP4.6ND120E310 still in production?
Yes — the Weichai WP4.6ND120E310 is a current production model.
Is a datasheet available for the WP4.6ND120E310?
Yes — an official Weichai datasheet for the Weichai WP4.6ND120E310 can be downloaded from this page.
