Xinchai
Xinchai 3B11YD41
The Xinchai 3B11YD41 is a 1.1-litre inline-3 diesel engine for generator sets, rated at 30 kVA / 24 kWe standby power at 3,000 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 30 kVA
- Electrical Output
- 24 kWe
- Cylinders
- L3
- Displacement
- 1.1 L
- Rated Speed
- 3,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz3000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 25 | 23 | 28.8 |
| Standby Power | 27 | 24 | 30 |
Xinchai 3B11YD41 generator set context
The Xinchai 3B11YD41 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 30 kVA / 24 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Xinchai |
| Model | 3B11YD41 |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 1.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Xinchai 3B11YD41?
The Xinchai 3B11YD41 is rated at 30 kVA standby / 29 kVA prime at 50 Hz (3,000 rpm).
Does the 3B11YD41 run at 50 Hz or 60 Hz?
The Xinchai 3B11YD41 is rated for 50 Hz (3,000 rpm).
What fuel does the Xinchai 3B11YD41 use?
The Xinchai 3B11YD41 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 3B11YD41?
The Xinchai 3B11YD41 is an inline-3 (3-cylinder) engine with a displacement of 1.1 L.
Is the Xinchai 3B11YD41 still in production?
Yes — the Xinchai 3B11YD41 is a current production model.
Is a datasheet available for the 3B11YD41?
Yes — an official Xinchai datasheet for the Xinchai 3B11YD41 can be downloaded from this page.
Related Engines
Compare Xinchai 3B11YD41
Reference
- Canonical page
- /engines/xinchai-3b11yd41
- Last database update
- 2026-06-08
- Manufacturer files
- 1 datasheet linked
