Xinchai
Xinchai 3E22RD
The Xinchai 3E22RD is a 2.2-litre inline-3 diesel engine for generator sets, rated at 50 kVA / 40 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 50 kVA
- Electrical Output
- 40 kWe
- Cylinders
- L3
- Displacement
- 2.2 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 40 | 36 | 45 |
| Standby Power | 44 | 40 | 50 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 49 | 44 | 55 |
| Standby Power | 54 | 49 | 61.3 |
Technical Specifications
| Brand | Xinchai |
| Model | 3E22RD |
| Configuration | L3 |
| Cylinders | 3 |
| Displacement | 2.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
