Caterpillar
Caterpillar C4.4
C Series
Caterpillar C4.4 4.4L 4-cylinder diesel engine for generator sets. 50 ekW standby at 60Hz / 45 ekW standby at 50Hz. U.S. EPA Tier 3. Turbocharged.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-28
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 56 kVA
- Electrical Output
- 45 kWe
- Cylinders
- L4
- Displacement
- 4.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 44.4 | 40 | 50 |
| Standby Power | 50 | 45 | 56.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 50 | 45 | 56.3 |
| Standby Power | 55.6 | 50 | 62.5 |
Ask about Caterpillar C4.4
Choose parts / service or sourcing. Your message includes this model and page link.
Caterpillar C4.4 overhaul & repair parts
Already running a Caterpillar C4.4? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with C4.4 and your selected categories included. Attach your photos there.
Caterpillar C4.4 generator set context
The Caterpillar C4.4 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 56 kVA / 45 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Caterpillar |
| Model | C4.4 |
| Series | C Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | United States |
Frequently asked questions
What is the power output of the Caterpillar C4.4?
The Caterpillar C4.4 is rated at 56 kVA standby / 50 kVA prime at 50 Hz (1,500 rpm); and 63 kVA standby / 56 kVA prime at 60 Hz (1,800 rpm).
Does the C4.4 run at 50 Hz or 60 Hz?
The Caterpillar C4.4 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Caterpillar C4.4 use?
The Caterpillar C4.4 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the C4.4?
The Caterpillar C4.4 is an inline-4 (4-cylinder) engine with a displacement of 4.4 L.
What emissions information is listed for the C4.4?
This record lists U.S. EPA Tier 3 for the Caterpillar C4.4. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Caterpillar C4.4?
The Caterpillar C4.4 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the C4.4?
This page links reference documents for the Caterpillar C4.4. Check each document's title, model coverage, revision and rating conditions before using it for selection.
