Googol
Googol QTA20V-EG2950D
Q Series
The Googol QTA20V-EG2950D is a 107.5-litre V20 diesel engine for generator sets, rated at 3,300 kVA / 2,640 kWe standby power at 1,500 RPM (50 Hz). It is a water-air-cooled engine built in China.
- Standby Power · 50 Hz
- 3,300 kVA
- Electrical Output
- 2,640 kWe
- Cylinders
- V20
- Displacement
- 107.5 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 2666.7 | 2400 | 3000 |
| Standby Power | 2933.3 | 2640 | 3300 |
Technical Specifications
| Brand | Googol |
| Model | QTA20V-EG2950D |
| Series | Q Series |
| Configuration | V20 |
| Cylinders | 20 |
| Displacement | 107.5 L |
| Dry Weight | 7800 kg |
| Dimensions (L×W×H) | 4170 × 1634 × 2130 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Water-Air |
| Emissions Standard | China National Stage III / Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Googol QTA20V-EG2950D?
The Googol QTA20V-EG2950D is rated at 3,300 kVA standby / 3,000 kVA prime at 50 Hz (1,500 rpm).
Does the QTA20V-EG2950D run at 50 Hz or 60 Hz?
The Googol QTA20V-EG2950D is rated for 50 Hz (1,500 rpm).
What fuel does the Googol QTA20V-EG2950D use?
The Googol QTA20V-EG2950D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the QTA20V-EG2950D?
The Googol QTA20V-EG2950D is a V20 (20-cylinder) engine with a displacement of 107.5 L.
Is the Googol QTA20V-EG2950D still in production?
Yes — the Googol QTA20V-EG2950D is a current production model.
Is a datasheet available for the QTA20V-EG2950D?
Yes — an official Googol datasheet for the Googol QTA20V-EG2950D can be downloaded from this page.
