Hyundai
Hyundai DP024CAP
DP024 Series
Hyundai DP024CAP 2.4L 4-cylinder diesel engine for generator sets. EPA Tier 4 Final certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP024CAP and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 46 kVA
- Electrical Output
- 37 kWe
- Cylinders
- L4
- Displacement
- 2.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37.8 | 34 | 42.5 |
| Standby Power | 41.1 | 37 | 46.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 45.6 | 41 | 51.3 |
| Standby Power | 48.9 | 44 | 55 |
Hyundai DP024CAP generator set context
The Hyundai DP024CAP is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 46 kVA / 37 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP024CAP |
| Series | DP024 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 2.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP024CAP?
The Hyundai DP024CAP is rated at 46 kVA standby / 43 kVA prime at 50 Hz (1,500 rpm); and 55 kVA standby / 51 kVA prime at 60 Hz (1,800 rpm).
Does the DP024CAP run at 50 Hz or 60 Hz?
The Hyundai DP024CAP is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP024CAP use?
The Hyundai DP024CAP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP024CAP?
The Hyundai DP024CAP is an inline-4 (4-cylinder) engine with a displacement of 2.4 L.
What emissions standard does the DP024CAP meet?
The Hyundai DP024CAP is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Hyundai DP024CAP still in production?
Yes — the Hyundai DP024CAP is a current production model.
Is a datasheet available for the DP024CAP?
Yes — an official Hyundai datasheet for the Hyundai DP024CAP can be downloaded from this page.
