Hyundai DP024CAV

Hyundai DP024CAV — 2.392-litre inline-4 diesel engine. Find specifications, documents and parts support below.

Production StatusIn Production

DM

Representative Hyundai engine
Electrical output 50 Hz · 1500 RPM
Prime power40 kWe
Standby power42 kWe
Configuration
L4
Displacement
2.392 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm4548
Electrical output kWe4042

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm4955
Electrical output kWe4348

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Source notes

Hyundai DP024CAV, DM common-rail generator-drive engine, 2.392 L L4.

Updated from the user-supplied Hyundai / Power Solutions Limited lineup dated 2026-10-07.

The sheet lists Euro Stage V; this is a lineup declaration, not an independently checked model-year certification certificate.

Mechanical engine kW and reference genset electrical kWe are stored separately.

Ratings are rounded reference values; final ratings require the specific engine technical datasheet and genset output depends on alternator efficiency.

Unlisted frequency ratings and unsupported kVA are left blank.

View DP024CAV spec image
Shareable spec cardHyundai DP024CAV summary imageOpen image
Hyundai DP024CAV 2.392L L4 diesel generator engine — 53 kVA standby specifications

Technical specifications

Technical Specifications

BrandHyundai
ModelDP024CAV
SeriesDM
ConfigurationL4
Cylinders4
Displacement2.392 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardEuro Stage V
Country of OriginSouth Korea

Check your engine model

The Hyundai DP024CAV is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 53 kVA / 42 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

dp024cavHyundai DP024CAVDM DP024CAV

DP024CAV repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate
Parts reference availability

We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Hyundai DP024CAV?

The Hyundai DP024CAV is rated at 53 kVA standby / 50 kVA prime at 50 Hz (1,500 rpm); and 60 kVA standby / 54 kVA prime at 60 Hz (1,800 rpm).

Does the DP024CAV run at 50 Hz or 60 Hz?

The Hyundai DP024CAV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Hyundai DP024CAV use?

The Hyundai DP024CAV is a diesel generator-set engine.

What is the displacement and cylinder configuration of the DP024CAV?

The Hyundai DP024CAV is an inline-4 (4-cylinder) engine with a displacement of 2.392 L.

What emissions information is listed for the DP024CAV?

This record lists Euro Stage V for the Hyundai DP024CAV. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.

What is the catalog status of the Hyundai DP024CAV?

The Hyundai DP024CAV is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the DP024CAV?

This page links reference documents for the Hyundai DP024CAV. Check each document's title, model coverage, revision and rating conditions before using it for selection.
