Hyundai
Hyundai DP034CCP
DP034 Series
Hyundai DP034CCP 3.4L 4-cylinder diesel engine for generator sets. EPA Tier 4 Final certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP034CCP and this page link filled in.
- Manufacturer files
- 3 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 86 kVA
- Electrical Output
- 69 kWe
- Cylinders
- L4
- Displacement
- 3.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 71.1 | 64 | 80 |
| Standby Power | 76.7 | 69 | 86.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 81.1 | 73 | 91.3 |
| Standby Power | 88.9 | 80 | 100 |
Hyundai DP034CCP generator set context
The Hyundai DP034CCP is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 86 kVA / 69 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP034CCP |
| Series | DP034 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Final Tier 4 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP034CCP?
The Hyundai DP034CCP is rated at 86 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 100 kVA standby / 91 kVA prime at 60 Hz (1,800 rpm).
Does the DP034CCP run at 50 Hz or 60 Hz?
The Hyundai DP034CCP is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP034CCP use?
The Hyundai DP034CCP is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP034CCP?
The Hyundai DP034CCP is an inline-4 (4-cylinder) engine with a displacement of 3.4 L.
What emissions standard does the DP034CCP meet?
The Hyundai DP034CCP is certified to U.S. EPA Final Tier 4 emissions standards.
Is the Hyundai DP034CCP still in production?
Yes — the Hyundai DP034CCP is a current production model.
Is a datasheet available for the DP034CCP?
Yes — an official Hyundai datasheet for the Hyundai DP034CCP can be downloaded from this page.
