Hyundai
Hyundai DP034CCV
DP034 Series
Hyundai DP034CCV 3.4L 4-cylinder diesel engine for generator sets. Euro Stage V certified.
- Standby Power · 50 Hz
- 86 kVA
- Electrical Output
- 69 kWe
- Cylinders
- L4
- Displacement
- 3.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 71.1 | 64 | 80 |
| Standby Power | 76.7 | 69 | 86.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 81.1 | 73 | 91.3 |
| Standby Power | 88.9 | 80 | 100 |
Technical Specifications
| Brand | Hyundai |
| Model | DP034CCV |
| Series | DP034 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP034CCV?
The Hyundai DP034CCV is rated at 86 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 100 kVA standby / 91 kVA prime at 60 Hz (1,800 rpm).
Does the DP034CCV run at 50 Hz or 60 Hz?
The Hyundai DP034CCV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP034CCV use?
The Hyundai DP034CCV is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP034CCV?
The Hyundai DP034CCV is an inline-4 (4-cylinder) engine with a displacement of 3.4 L.
What emissions standard does the DP034CCV meet?
The Hyundai DP034CCV is certified to Euro Stage V emissions standards.
Is the Hyundai DP034CCV still in production?
Yes — the Hyundai DP034CCV is a current production model.
Is a datasheet available for the DP034CCV?
Yes — an official Hyundai datasheet for the Hyundai DP034CCV can be downloaded from this page.
