Hyundai
Hyundai DP054CA
DP054 Series
Hyundai DP054CA 5L 4-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Overhaul & repair parts- Supporting documents
- 4 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 139 kVA
- Electrical Output
- 111 kWe
- Cylinders
- L4
- Displacement
- 5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 112.2 | 101 | 126.3 |
| Standby Power | 123.3 | 111 | 138.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 131.1 | 118 | 147.5 |
| Standby Power | 145.6 | 131 | 163.8 |
Ask about Hyundai DP054CA
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP054CA overhaul & repair parts
Already running a Hyundai DP054CA? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP054CA and your selected categories included. Attach your photos there.
Hyundai DP054CA generator set context
The Hyundai DP054CA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 139 kVA / 111 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP054CA |
| Series | DP054 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP054CA?
The Hyundai DP054CA is rated at 139 kVA standby / 126 kVA prime at 50 Hz (1,500 rpm); and 164 kVA standby / 148 kVA prime at 60 Hz (1,800 rpm).
Does the DP054CA run at 50 Hz or 60 Hz?
The Hyundai DP054CA is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP054CA use?
The Hyundai DP054CA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP054CA?
The Hyundai DP054CA is an inline-4 (4-cylinder) engine with a displacement of 5 L.
What is the catalog status of the Hyundai DP054CA?
The Hyundai DP054CA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP054CA?
This page links reference documents for the Hyundai DP054CA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
