Hyundai
Hyundai DP054CB
DP054 Series
Hyundai DP054CB 5L 4-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP054CB and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 175 kVA
- Electrical Output
- 140 kWe
- Cylinders
- L4
- Displacement
- 5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 141.1 | 127 | 158.8 |
| Standby Power | 155.6 | 140 | 175 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 154.4 | 139 | 173.8 |
| Standby Power | 171.1 | 154 | 192.5 |
Hyundai DP054CB generator set context
The Hyundai DP054CB is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 175 kVA / 140 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP054CB |
| Series | DP054 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP054CB?
The Hyundai DP054CB is rated at 175 kVA standby / 159 kVA prime at 50 Hz (1,500 rpm); and 193 kVA standby / 174 kVA prime at 60 Hz (1,800 rpm).
Does the DP054CB run at 50 Hz or 60 Hz?
The Hyundai DP054CB is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP054CB use?
The Hyundai DP054CB is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP054CB?
The Hyundai DP054CB is an inline-4 (4-cylinder) engine with a displacement of 5 L.
Is the Hyundai DP054CB still in production?
Yes — the Hyundai DP054CB is a current production model.
Is a datasheet available for the DP054CB?
Yes — an official Hyundai datasheet for the Hyundai DP054CB can be downloaded from this page.
