Haifeng Machinery

Hyundai P158LE

Hyundai P158LE 14.6L 8-cylinder diesel engine for generator sets. Unregulated (no emission certification).

Production StatusIn Production

P158LE Series

Representative Hyundai engine
Electrical output 50 Hz · 1500 RPM
Prime power326 kWe
Standby power374 kWe
Configuration
L8
Displacement
14.6 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm362.2415.6
Electrical output kWe326374
Apparent power kVA407.5467.5

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm394.4453.3
Electrical output kWe355408
Apparent power kVA443.8510

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Technical specifications

Technical Specifications

BrandHyundai
ModelP158LE
SeriesP158LE Series
ConfigurationL8
Cylinders8
Displacement14.6 L
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardUnregulated
Country of OriginSouth Korea

Check your engine model

The Hyundai P158LE is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 468 kVA / 374 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

p158leHyundai P158LEP158LE Series P158LE

P158LE repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

These categories have model-related records. Part numbers need further checking before we display them here.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Hyundai P158LE?

The Hyundai P158LE is rated at 468 kVA standby / 408 kVA prime at 50 Hz (1,500 rpm); and 510 kVA standby / 444 kVA prime at 60 Hz (1,800 rpm).

Does the P158LE run at 50 Hz or 60 Hz?

The Hyundai P158LE is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Hyundai P158LE use?

The Hyundai P158LE is a diesel generator-set engine.

What is the displacement and cylinder configuration of the P158LE?

The Hyundai P158LE is an inline-8 (8-cylinder) engine with a displacement of 14.6 L.

What is the catalog status of the Hyundai P158LE?

The Hyundai P158LE is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the P158LE?

This page links reference documents for the Hyundai P158LE. Check each document's title, model coverage, revision and rating conditions before using it for selection.
