Hyundai
Hyundai SP344CC
SP344 Series
Hyundai SP344CC 3.4L 4-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Overhaul & repair parts- Supporting documents
- 2 documents · 1 datasheet
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 88 kVA
- Electrical Output
- 70 kWe
- Cylinders
- L4
- Displacement
- 3.4 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 71.1 | 64 | 80 |
| Standby Power | 77.8 | 70 | 87.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 80 | 72 | 90 |
| Standby Power | 87.8 | 79 | 98.8 |
Ask about Hyundai SP344CC
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai SP344CC overhaul & repair parts
Already running a Hyundai SP344CC? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with SP344CC and your selected categories included. Attach your photos there.
Hyundai SP344CC generator set context
The Hyundai SP344CC is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 88 kVA / 70 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | SP344CC |
| Series | SP344 Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.4 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai SP344CC?
The Hyundai SP344CC is rated at 88 kVA standby / 80 kVA prime at 50 Hz (1,500 rpm); and 99 kVA standby / 90 kVA prime at 60 Hz (1,800 rpm).
Does the SP344CC run at 50 Hz or 60 Hz?
The Hyundai SP344CC is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai SP344CC use?
The Hyundai SP344CC is a diesel generator-set engine.
What is the displacement and cylinder configuration of the SP344CC?
The Hyundai SP344CC is an inline-4 (4-cylinder) engine with a displacement of 3.4 L.
What is the catalog status of the Hyundai SP344CC?
The Hyundai SP344CC is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the SP344CC?
This page links reference documents for the Hyundai SP344CC. Check each document's title, model coverage, revision and rating conditions before using it for selection.
