Jichai
Jichai JC15D2
140 series
Jichai JC15D2 — 15.2 L L6 (140 × 165 mm) common-rail turbocharged diesel generator engine (CNPC Jichai 140 series, genset 450GF30). 503 kW engine / 450 kWe genset at 1500 rpm, GB20891 Stage III, ≤190 g/kWh.
- Prime Power · 50 Hz
- 563 kVA
- Electrical Output
- 450 kWe
- Cylinders
- L6
- Displacement
- 15.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 450 | 562.5 |
Jichai JC15D2 generator set context
The Jichai JC15D2 is listed here as a diesel generator-drive engine for 50 Hz generator sets, with a headline 563 kVA / 450 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | JC15D2 |
| Series | 140 series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.2 L |
| Dry Weight | 4600 kg |
| Dimensions (L×W×H) | 3570 × 1274 × 1700 mm |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai JC15D2?
The Jichai JC15D2 is rated at 563 kVA prime at 50 Hz (1,500 rpm).
Does the JC15D2 run at 50 Hz or 60 Hz?
The Jichai JC15D2 is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai JC15D2 use?
The Jichai JC15D2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the JC15D2?
The Jichai JC15D2 is an inline-6 (6-cylinder) engine with a displacement of 15.2 L.
What emissions standard does the JC15D2 meet?
The Jichai JC15D2 is certified to China III (GB20891) emissions standards.
Is the Jichai JC15D2 still in production?
Yes — the Jichai JC15D2 is a current production model.
