Jichai
Jichai JC15T
140 series
Jichai JC15T — 15.2 L L6 (140 × 165 mm) spark-ignited lean-burn gas generator engine (CNPC Jichai 140/JC15 series, genset 300GF30-T). 350 kW engine / 300 kWe at 1500 rpm, runs natural gas; GB20891 Stage III, 0.27 Nm³/kWh.
- Prime Power · 50 Hz
- 375 kVA
- Electrical Output
- 300 kWe
- Cylinders
- L6
- Displacement
- 15.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 300 | 375 |
Jichai JC15T generator set context
The Jichai JC15T is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 375 kVA / 300 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | JC15T |
| Series | 140 series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.2 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai JC15T?
The Jichai JC15T is rated at 375 kVA prime at 50 Hz (1,500 rpm).
Does the JC15T run at 50 Hz or 60 Hz?
The Jichai JC15T is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai JC15T use?
The Jichai JC15T is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the JC15T?
The Jichai JC15T is an inline-6 (6-cylinder) engine with a displacement of 15.2 L.
What emissions standard does the JC15T meet?
The Jichai JC15T is certified to China III (GB20891) emissions standards.
Is the Jichai JC15T still in production?
Yes — the Jichai JC15T is a current production model.
