Jichai
Jichai JC15T1
140 series
Jichai JC15T1 — 15.2 L L6 (140 × 165 mm) spark-ignited lean-burn gas generator engine (CNPC Jichai 140/JC15 series, genset 250GF30-T). 300 kW engine / 250 kWe at 1500 rpm, runs natural gas; GB20891 Stage III, 0.27 Nm³/kWh.
- Prime Power · 50 Hz
- 313 kVA
- Electrical Output
- 250 kWe
- Cylinders
- L6
- Displacement
- 15.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 250 | 312.5 |
Jichai JC15T1 generator set context
The Jichai JC15T1 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 313 kVA / 250 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | JC15T1 |
| Series | 140 series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.2 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai JC15T1?
The Jichai JC15T1 is rated at 313 kVA prime at 50 Hz (1,500 rpm).
Does the JC15T1 run at 50 Hz or 60 Hz?
The Jichai JC15T1 is rated for 50 Hz (1,500 rpm).
What fuel does the Jichai JC15T1 use?
The Jichai JC15T1 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the JC15T1?
The Jichai JC15T1 is an inline-6 (6-cylinder) engine with a displacement of 15.2 L.
What emissions standard does the JC15T1 meet?
The Jichai JC15T1 is certified to China III (GB20891) emissions standards.
Is the Jichai JC15T1 still in production?
Yes — the Jichai JC15T1 is a current production model.
