Jichai
Jichai JC15Z
140 series
Jichai JC15Z — 15.2 L L6 (140 × 165 mm) spark-ignited lean-burn gas generator engine (CNPC Jichai 140/JC15 series, genset 300GF30-N). 350 kW engine / 300 kWe at 1500 rpm, runs biogas (沼气); GB20891 Stage III, 0.27 Nm³/kWh.
- Prime Power · 50 Hz
- 375 kVA
- Electrical Output
- 300 kWe
- Cylinders
- L6
- Displacement
- 15.2 L
- Rated Speed
- 1,500 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 300 | 375 |
Technical Specifications
| Brand | Jichai |
| Model | JC15Z |
| Series | 140 series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 15.2 L |
| Fuel Type | Biogas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | China III (GB20891) |
| Country of Origin | China |
