Kubota

Kubota V2403-M-DI-BG-CHN-1T

V Series

In Production

The Kubota V2403-M-DI-BG-CHN-1T is a 2.403-litre inline-4 diesel engine for generator sets, rated at 26 kVA / 21 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.

Get help with this engine

Tell Haifeng whether you already own a Kubota V2403-M-DI-BG-CHN-1T engine/generator or need to source this model for a project.

I need service / overhaul supportFor overhaul, parts, documents, troubleshooting, or replacement matching.For clients who already have this engine or generator: overhaul, spare parts, documentation, troubleshooting, or replacement matching.WhatsApp service request I need to source this engineFor projects, tenders, overseas sourcing, availability, or equivalents.For projects, client leads, tenders, overseas sourcing, package availability, or acceptable equivalents.WhatsApp sourcing request

Request datasheet Compare engine Get a quote

Manufacturer files: No datasheet
Last updated: 2026-07-01
Package route: diesel generator sets

Standby Power · 50 Hz: 26 kVA
Electrical Output: 21 kWe
Cylinders: L4
Displacement: 2.403 L
Rated Speed: 1,500 / 1,800 RPM

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

	kWm	kWe	kVA
Prime Power	21.1	19	23.8
Standby Power	23.3	21	26.3

60 Hz1800 RPM

	kWm	kWe	kVA
Prime Power	24.4	22	27.5
Standby Power	26.7	24	30

Kubota V2403-M-DI-BG-CHN-1T 2.403L L4 diesel generator engine — 26 kVA standby specifications — Shareable spec cardKubota V2403-M-DI-BG-CHN-1T summary imageOpen image

Kubota V2403-M-DI-BG-CHN-1T generator set context

The Kubota V2403-M-DI-BG-CHN-1T is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 26 kVA / 21 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.

Also searched as

v2403mdibgchn1tV2403 M DI BG CHN 1TKubota V2403-M-DI-BG-CHN-1TV Series V2403-M-DI-BG-CHN-1T

BrandAll Kubota engines CompareSimilar engines Haifeng packagediesel generator sets

Technical Specifications

Brand	Kubota
Model	V2403-M-DI-BG-CHN-1T
Series	V Series
Configuration	L4
Cylinders	4
Displacement	2.403 L
Fuel Type	Diesel
Ignition Type	Compression Ignition
Cooling Method	Liquid-Cooled
Emissions Standard	Unregulated
Country of Origin	Japan

Frequently asked questions

What is the power output of the Kubota V2403-M-DI-BG-CHN-1T?

The Kubota V2403-M-DI-BG-CHN-1T is rated at 26 kVA standby / 24 kVA prime at 50 Hz (1,500 rpm); and 30 kVA standby / 28 kVA prime at 60 Hz (1,800 rpm).

Does the V2403-M-DI-BG-CHN-1T run at 50 Hz or 60 Hz?

The Kubota V2403-M-DI-BG-CHN-1T is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Kubota V2403-M-DI-BG-CHN-1T use?

The Kubota V2403-M-DI-BG-CHN-1T is a diesel generator-set engine.

What is the displacement and cylinder configuration of the V2403-M-DI-BG-CHN-1T?

The Kubota V2403-M-DI-BG-CHN-1T is an inline-4 (4-cylinder) engine with a displacement of 2.403 L.
