Kubota
Kubota V3800DI-T-E2BG-CHN-2
V Series
The Kubota V3800DI-T-E2BG-CHN-2 is a 3.8-litre inline-4 diesel engine for generator sets, rated at 48 kVA / 38 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in Japan.
- Standby Power · 50 Hz
- 48 kVA
- Electrical Output
- 38 kWe
- Cylinders
- L4
- Displacement
- 3.8 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 37.8 | 34 | 42.5 |
| Standby Power | 42.2 | 38 | 47.5 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 46.7 | 42 | 52.5 |
| Standby Power | 51.1 | 46 | 57.5 |
Technical Specifications
| Brand | Kubota |
| Model | V3800DI-T-E2BG-CHN-2 |
| Series | V Series |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Japan |
Frequently asked questions
What is the power output of the Kubota V3800DI-T-E2BG-CHN-2?
The Kubota V3800DI-T-E2BG-CHN-2 is rated at 48 kVA standby / 43 kVA prime at 50 Hz (1,500 rpm); and 58 kVA standby / 53 kVA prime at 60 Hz (1,800 rpm).
Does the V3800DI-T-E2BG-CHN-2 run at 50 Hz or 60 Hz?
The Kubota V3800DI-T-E2BG-CHN-2 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Kubota V3800DI-T-E2BG-CHN-2 use?
The Kubota V3800DI-T-E2BG-CHN-2 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the V3800DI-T-E2BG-CHN-2?
The Kubota V3800DI-T-E2BG-CHN-2 is an inline-4 (4-cylinder) engine with a displacement of 3.8 L.
Is the Kubota V3800DI-T-E2BG-CHN-2 still in production?
Yes — the Kubota V3800DI-T-E2BG-CHN-2 is a current production model.
Is a datasheet available for the V3800DI-T-E2BG-CHN-2?
Yes — an official Kubota datasheet for the Kubota V3800DI-T-E2BG-CHN-2 can be downloaded from this page.
Related Engines
Compare Kubota V3800DI-T-E2BG-CHN-2
Reference
- Canonical page
- /engines/kubota-v3800di-t-e2bg-chn-2
- Last database update
- 2026-07-01
- Manufacturer files
- 1 datasheet linked
