Liebherr
D976
D9 Series
Liebherr D976 18L 6-cylinder diesel engine for generator sets. 650 kWm standby at 1500rpm. Euro Stage V. kWe estimated at 96% alternator efficiency.
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf · kWe estimated — see note below
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 580 | 556.8 | 696 |
| Standby Power | 650 | 624 | 780 |
Note: The manufacturer does not publish a separate kWe rating for this engine. kWe values shown are estimated from the rated mechanical output (kWm) using a conservative 90% alternator efficiency factor.
Technical Specifications
| Brand | Liebherr |
| Model | D976 |
| Series | D9 Series |
| Configuration | In-line 6, Turbocharged Intercooled |
| Cylinders | 6 |
| Displacement | 18 L |
| Fuel Type | Diesel |
| Emissions Standard | Euro Stage V |
| Country of Origin | Switzerland |
