MWM
MWM TCG 2032 V16
TCG 2032
MWM TCG 2032 V16 — 271.8 L V16 spark-ignition gas engine (TCG 2032 series), multi-fuel: natural gas, biogas and sewage/landfill gas. 4300 kWe at 1000 rpm / 50 Hz, 4000 kWe at 900 rpm / 60 Hz; NOx ≤ 500 mg/Nm³.
- Prime Power · 50 Hz
- 5,375 kVA
- Electrical Output
- 4,300 kWe
- Cylinders
- V16
- Displacement
- 271.8 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4300 | 5375 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4000 | 5000 |
Technical Specifications
| Brand | MWM |
| Model | TCG 2032 V16 |
| Series | TCG 2032 |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 271.8 L |
| Dry Weight | 51200 kg |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | Germany |
