Weichai WP6D167E200

Weichai WP6D167E200 — 6.1-litre inline-6 diesel engine. Find specifications, documents and parts support below.

Production StatusIn Production

WP Series

Representative Weichai engine
Electrical output 50 Hz · 1500 RPM
Standby power150 kWe
Configuration
L6
Displacement
6.1 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingStandby
Mechanical power kWm167
Electrical output kWe150
Apparent power kVA187.5

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm164.4180
Electrical output kWe148162
Apparent power kVA185202.5

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Source notes

2026-10-21 manufacturer-source revision: Source: 发动机数据单-WP6-0004_WP6D167E200_NonRad无散热器_Datasheet_26-03-01.pdf, p.1.

Gross engine mechanical PRP 152 kW / ESP 167 kW at 1500 rpm.

Net power is configuration-dependent and separate from gross mechanical output; no electrical genset output inferred.

ESP applications only: all printed PRP figures are reference only and not supported prime-duty ratings.

This revision supersedes conflicting rating/duty statements above for the documented configuration; other configurations are not inferred.

Physical specifications added from manufacturer datasheets, 2026-10-21: compression ratio 18:1; dry engine weight 680 kg without radiator and radiator pipes; overall dimensions without radiator (L × W × H) 1524 × 779 × 1122 mm.

Sources: 发动机数据单-WP6-0004_WP6D167E200_NonRad无散热器_Datasheet_26-03-01.pdf (physical data on pp.1–2).

Existing populated specification fields were not overwritten.

Weight is dry engine weight, not genset shipping weight.

View WP6D167E200 spec image
Shareable spec cardWeichai WP6D167E200 summary imageOpen image
Weichai WP6D167E200 6.1L L6 diesel generator engine — 188 kVA standby specifications

Technical specifications

Technical Specifications

BrandWeichai
ModelWP6D167E200
SeriesWP Series
ConfigurationL6
Cylinders6
Displacement6.1 L
Compression Ratio18:1
Dry Weight680 kg
Dimensions (L×W×H)1524 × 779 × 1122 mm
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardChina National Stage II / Unregulated
Country of OriginChina

Check your engine model

The Weichai WP6D167E200 is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 188 kVA / 150 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

wp6d167e200Weichai WP6D167E200WP Series WP6D167E200

WP6D167E200 repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

These categories have model-related records. Part numbers need further checking before we display them here.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Weichai WP6D167E200?

The Weichai WP6D167E200 is rated at 188 kVA standby at 50 Hz (1,500 rpm); and 203 kVA standby / 185 kVA prime at 60 Hz (1,800 rpm).

Does the WP6D167E200 run at 50 Hz or 60 Hz?

The Weichai WP6D167E200 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Weichai WP6D167E200 use?

The Weichai WP6D167E200 is a diesel generator-set engine.

What is the displacement and cylinder configuration of the WP6D167E200?

The Weichai WP6D167E200 is an inline-6 (6-cylinder) engine with a displacement of 6.1 L.

What is the catalog status of the Weichai WP6D167E200?

The Weichai WP6D167E200 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the WP6D167E200?

This page links reference documents for the Weichai WP6D167E200. Check each document's title, model coverage, revision and rating conditions before using it for selection.
