Xinchai
Xinchai 4E30YD
The Xinchai 4E30YD is a 3-litre inline-4 diesel engine for generator sets, rated at 61 kVA / 49 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
Overhaul & repair parts- Manufacturer files
- 3 datasheets
- Last updated
- 2026-06-08
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 61 kVA
- Electrical Output
- 49 kWe
- Cylinders
- L4
- Displacement
- 3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 49 | 44 | 55 |
| Standby Power | 54 | 49 | 61.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 54 | 49 | 61.3 |
| Standby Power | 60 | 54 | 67.5 |
Ask about Xinchai 4E30YD
Choose parts / service or sourcing. Your message includes this model and page link.
Xinchai 4E30YD overhaul & repair parts
Already running a Xinchai 4E30YD? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 4E30YD and your selected categories included. Attach your photos there.
Xinchai 4E30YD generator set context
The Xinchai 4E30YD is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 61 kVA / 49 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Xinchai |
| Model | 4E30YD |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Xinchai 4E30YD?
The Xinchai 4E30YD is rated at 61 kVA standby / 55 kVA prime at 50 Hz (1,500 rpm); and 68 kVA standby / 61 kVA prime at 60 Hz (1,800 rpm).
Does the 4E30YD run at 50 Hz or 60 Hz?
The Xinchai 4E30YD is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Xinchai 4E30YD use?
The Xinchai 4E30YD is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 4E30YD?
The Xinchai 4E30YD is an inline-4 (4-cylinder) engine with a displacement of 3 L.
What is the catalog status of the Xinchai 4E30YD?
The Xinchai 4E30YD is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the 4E30YD?
This page links reference documents for the Xinchai 4E30YD. Check each document's title, model coverage, revision and rating conditions before using it for selection.
