Xinchai
Xinchai 4K41RD
The Xinchai 4K41RD is a 4.1-litre inline-4 diesel engine for generator sets, rated at 119 kVA / 95 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 119 kVA
- Electrical Output
- 95 kWe
- Cylinders
- L4
- Displacement
- 4.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 95 | 86 | 107.5 |
| Standby Power | 105 | 95 | 118.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 105 | 95 | 118.8 |
| Standby Power | 116 | 104 | 130 |
Technical Specifications
| Brand | Xinchai |
| Model | 4K41RD |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 4.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
