Xinchai
Xinchai A498BD
The Xinchai A498BD is a 3.2-litre inline-4 diesel engine for generator sets, rated at 40 kVA / 32 kWe standby power at 1,500 RPM (50 Hz). It is a liquid-cooled engine built in China.
- Standby Power · 50 Hz
- 40 kVA
- Electrical Output
- 32 kWe
- Cylinders
- L4
- Displacement
- 3.2 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 32 | 29 | 36.3 |
| Standby Power | 35 | 32 | 40 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 38 | 34 | 42.5 |
| Standby Power | 42 | 38 | 47.5 |
Technical Specifications
| Brand | Xinchai |
| Model | A498BD |
| Configuration | L4 |
| Cylinders | 4 |
| Displacement | 3.2 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
