Hyundai DP180LA
DP180 Series
Hyundai DP180LA 18.3L (approx.) 6-cylinder diesel engine for generator sets. 507 kWe standby at 50Hz / 555 kWe at 60Hz. Unregulated. Turbocharged Intercooled.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 634 kVA
- Electrical Output
- 507 kWe
- Cylinders
- L6
- Displacement
- 18.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 512.2 | 461 | 576.3 |
| Standby Power | 563.3 | 507 | 633.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 562.2 | 506 | 632.5 |
| Standby Power | 616.7 | 555 | 693.8 |
Ask about Hyundai DP180LA
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP180LA overhaul & repair parts
Already running a Hyundai DP180LA? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP180LA and your selected categories included. Attach your photos there.
Hyundai DP180LA generator set context
The Hyundai DP180LA is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 634 kVA / 507 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP180LA |
| Series | DP180 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP180LA?
The Hyundai DP180LA is rated at 634 kVA standby / 576 kVA prime at 50 Hz (1,500 rpm); and 694 kVA standby / 633 kVA prime at 60 Hz (1,800 rpm).
Does the DP180LA run at 50 Hz or 60 Hz?
The Hyundai DP180LA is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP180LA use?
The Hyundai DP180LA is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP180LA?
The Hyundai DP180LA is an inline-6 (6-cylinder) engine with a displacement of 18.3 L.
What is the catalog status of the Hyundai DP180LA?
The Hyundai DP180LA is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP180LA?
This page links reference documents for the Hyundai DP180LA. Check each document's title, model coverage, revision and rating conditions before using it for selection.
