Hyundai
Hyundai DP180LB
DP180 Series
Hyundai DP180LB 18.3L (approx.) 6-cylinder diesel engine for generator sets. 564 kWe standby at 50Hz / 604 kWe at 60Hz. Unregulated. Turbocharged Intercooled.
Overhaul & repair parts- Manufacturer files
- 1 datasheet
- Last updated
- 2026-06-11
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 705 kVA
- Electrical Output
- 564 kWe
- Cylinders
- L6
- Displacement
- 18.3 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 570 | 513 | 641.3 |
| Standby Power | 626.7 | 564 | 705 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 608.9 | 548 | 685 |
| Standby Power | 671.1 | 604 | 755 |
Ask about Hyundai DP180LB
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP180LB overhaul & repair parts
Already running a Hyundai DP180LB? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP180LB and your selected categories included. Attach your photos there.
Hyundai DP180LB generator set context
The Hyundai DP180LB is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 705 kVA / 564 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP180LB |
| Series | DP180 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 18.3 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP180LB?
The Hyundai DP180LB is rated at 705 kVA standby / 641 kVA prime at 50 Hz (1,500 rpm); and 755 kVA standby / 685 kVA prime at 60 Hz (1,800 rpm).
Does the DP180LB run at 50 Hz or 60 Hz?
The Hyundai DP180LB is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP180LB use?
The Hyundai DP180LB is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP180LB?
The Hyundai DP180LB is an inline-6 (6-cylinder) engine with a displacement of 18.3 L.
What is the catalog status of the Hyundai DP180LB?
The Hyundai DP180LB is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP180LB?
This page links reference documents for the Hyundai DP180LB. Check each document's title, model coverage, revision and rating conditions before using it for selection.
