Hyundai
Hyundai P086TI-1
P086TI Series
Hyundai P086TI-1 8.1L 6-cylinder diesel engine for generator sets. Unregulated (no emission certification).
Overhaul & repair parts- Supporting documents
- 3 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 185 kVA
- Electrical Output
- 148 kWe
- Cylinders
- L6
- Displacement
- 8.1 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 148.9 | 134 | 167.5 |
| Standby Power | 164.4 | 148 | 185 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 171.1 | 154 | 192.5 |
| Standby Power | 188.9 | 170 | 212.5 |
Ask about Hyundai P086TI-1
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai P086TI-1 overhaul & repair parts
Already running a Hyundai P086TI-1? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with P086TI-1 and your selected categories included. Attach your photos there.
Hyundai P086TI-1 generator set context
The Hyundai P086TI-1 is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 185 kVA / 148 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | P086TI-1 |
| Series | P086TI Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 8.1 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai P086TI-1?
The Hyundai P086TI-1 is rated at 185 kVA standby / 168 kVA prime at 50 Hz (1,500 rpm); and 213 kVA standby / 193 kVA prime at 60 Hz (1,800 rpm).
Does the P086TI-1 run at 50 Hz or 60 Hz?
The Hyundai P086TI-1 is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai P086TI-1 use?
The Hyundai P086TI-1 is a diesel generator-set engine.
What is the displacement and cylinder configuration of the P086TI-1?
The Hyundai P086TI-1 is an inline-6 (6-cylinder) engine with a displacement of 8.1 L.
What is the catalog status of the Hyundai P086TI-1?
The Hyundai P086TI-1 is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the P086TI-1?
This page links reference documents for the Hyundai P086TI-1. Check each document's title, model coverage, revision and rating conditions before using it for selection.
