Jichai
Jichai 16V26/32-G
260 series
Jichai 16V26/32-G — 271.8 L V16 (260 × 320 mm) spark-ignited natural gas generator engine (CNPC Jichai 260 gas series, gensets 4000GF (1000rpm/50Hz) / 3600GF (900rpm/60Hz)). 4000 kWe @ 1000 rpm/50 Hz, 3600 kWe @ 900 rpm/60 Hz; turbocharged with two-stage intercooling, multi-point injection, closed-loop AFR; electrical efficiency ≥43%, heat rate ≤8100 kJ/kWh, 35,000 h overhaul interval; IMO Tier II / China marine Stage II.
- Prime Power · 50 Hz
- 5,000 kVA
- Electrical Output
- 4,000 kWe
- Cylinders
- V16
- Displacement
- 271.8 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4000 | 5000 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 3600 | 4500 |
Technical Specifications
| Brand | Jichai |
| Model | 16V26/32-G |
| Series | 260 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 271.8 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
