Jichai
Jichai 12V26/32-G
260 series
Jichai 12V26/32-G — 203.9 L V12 (260 × 320 mm) spark-ignited natural gas generator engine (CNPC Jichai 260 gas series, gensets 3000GF (1000rpm/50Hz) / 2700GF (900rpm/60Hz)). 3000 kWe @ 1000 rpm/50 Hz, 2700 kWe @ 900 rpm/60 Hz; turbocharged with two-stage intercooling, multi-point injection, closed-loop AFR; electrical efficiency ≥43%, heat rate ≤8100 kJ/kWh, 35,000 h overhaul interval; IMO Tier II / China marine Stage II.
Overhaul & repair parts- Manufacturer files
- No datasheet
- Last updated
- 2026-06-10
- Package route
- gas generator sets
- Prime Power · 50 Hz
- 3,750 kVA
- Electrical Output
- 3,000 kWe
- Cylinders
- V12
- Displacement
- 203.9 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 3000 | 3750 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 2700 | 3375 |
Ask about Jichai 12V26/32-G
Choose parts / service or sourcing. Your message includes this model and page link.
Jichai 12V26/32-G overhaul & repair parts
Already running a Jichai 12V26/32-G? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
Start with engine identification
We do not have a reviewed public parts preview for this model yet. Send the engine details and tell us what needs repair.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with 12V26/32-G and your selected categories included. Attach your photos there.
Jichai 12V26/32-G generator set context
The Jichai 12V26/32-G is listed here as a natural gas generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 3,750 kVA / 3,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | 12V26/32-G |
| Series | 260 series |
| Configuration | V12 |
| Cylinders | 12 |
| Displacement | 203.9 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai 12V26/32-G?
The Jichai 12V26/32-G is rated at 3,750 kVA prime at 50 Hz (1,000 rpm); and 3,375 kVA prime at 60 Hz (1,200 rpm).
Does the 12V26/32-G run at 50 Hz or 60 Hz?
The Jichai 12V26/32-G is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Jichai 12V26/32-G use?
The Jichai 12V26/32-G is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 12V26/32-G?
The Jichai 12V26/32-G is a V12 (12-cylinder) engine with a displacement of 203.9 L.
What emissions information is listed for the 12V26/32-G?
This record lists IMO Tier II for the Jichai 12V26/32-G. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Jichai 12V26/32-G?
The Jichai 12V26/32-G is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
