Jichai
Jichai 16V26/32
260 series
Jichai 16V26/32 — 271.8 L V16 (260 × 320 mm) spark-ignited gas generator engine (CNPC Jichai). 3600–4000 kWe at 1000 rpm; runs natural gas, biogas or coal-mine gas (CBM). CNPC's flagship engine line for oilfield and stationary power.
- Prime Power · 50 Hz
- 5,000 kVA
- Electrical Output
- 4,000 kWe
- Cylinders
- V16
- Displacement
- 271.8 L
- Rated Speed
- 1,000 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4000 | 5000 |
Jichai 16V26/32 generator set context
The Jichai 16V26/32 is listed here as a natural gas generator-drive engine for 50 Hz generator sets, with a headline 5,000 kVA / 4,000 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | 16V26/32 |
| Series | 260 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 271.8 L |
| Fuel Type | Natural Gas |
| Ignition Type | Spark Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Unregulated |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai 16V26/32?
The Jichai 16V26/32 is rated at 5,000 kVA prime at 50 Hz (1,000 rpm).
Does the 16V26/32 run at 50 Hz or 60 Hz?
The Jichai 16V26/32 is rated for 50 Hz (1,000 rpm).
What fuel does the Jichai 16V26/32 use?
The Jichai 16V26/32 is a Natural Gas generator-set engine.
What is the displacement and cylinder configuration of the 16V26/32?
The Jichai 16V26/32 is a V16 (16-cylinder) engine with a displacement of 271.8 L.
Is the Jichai 16V26/32 still in production?
Yes — the Jichai 16V26/32 is a current production model.
Is a datasheet available for the 16V26/32?
Yes — an official Jichai datasheet for the Jichai 16V26/32 can be downloaded from this page.
