Jichai
Jichai 16V26/32-D
260 series
Jichai 16V26/32-D — 271.8 L V16 (260 × 320 mm) common-rail turbocharged DIESEL generator engine (CNPC Jichai 260 series). 4800–5300 kWe at 900/1000 rpm (60/50 Hz), 400 V–13.8 kV; IMO Tier II / China marine II, ≤180 g/kWh.
- Prime Power · 50 Hz
- 6,625 kVA
- Electrical Output
- 5,300 kWe
- Cylinders
- V16
- Displacement
- 271.8 L
- Rated Speed
- 1,000 / 1,200 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1000 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 5300 | 6625 |
60 Hz1200 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | — | 4800 | 6000 |
Jichai 16V26/32-D generator set context
The Jichai 16V26/32-D is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 6,625 kVA / 5,300 kWe / prime rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Jichai |
| Model | 16V26/32-D |
| Series | 260 series |
| Configuration | V16 |
| Cylinders | 16 |
| Displacement | 271.8 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | IMO Tier II |
| Country of Origin | China |
Frequently asked questions
What is the power output of the Jichai 16V26/32-D?
The Jichai 16V26/32-D is rated at 6,625 kVA prime at 50 Hz (1,000 rpm); and 6,000 kVA prime at 60 Hz (1,200 rpm).
Does the 16V26/32-D run at 50 Hz or 60 Hz?
The Jichai 16V26/32-D is available for both 50 Hz (1,000 rpm) and 60 Hz (1,200 rpm).
What fuel does the Jichai 16V26/32-D use?
The Jichai 16V26/32-D is a diesel generator-set engine.
What is the displacement and cylinder configuration of the 16V26/32-D?
The Jichai 16V26/32-D is a V16 (16-cylinder) engine with a displacement of 271.8 L.
What emissions standard does the 16V26/32-D meet?
The Jichai 16V26/32-D is certified to IMO Tier II emissions standards.
Is the Jichai 16V26/32-D still in production?
Yes — the Jichai 16V26/32-D is a current production model.
