Hyundai
Hyundai DP086CAK
DP086 Series
Hyundai DP086CAK 7.5L 6-cylinder diesel engine for generator sets. EPA Tier 3 certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CAK and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 239 kVA
- Electrical Output
- 191 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 192.2 | 173 | 216.3 |
| Standby Power | 212.2 | 191 | 238.8 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 211.1 | 190 | 237.5 |
| Standby Power | 232.2 | 209 | 261.3 |
Hyundai DP086CAK generator set context
The Hyundai DP086CAK is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 239 kVA / 191 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CAK |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CAK?
The Hyundai DP086CAK is rated at 239 kVA standby / 216 kVA prime at 50 Hz (1,500 rpm); and 261 kVA standby / 238 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CAK run at 50 Hz or 60 Hz?
The Hyundai DP086CAK is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CAK use?
The Hyundai DP086CAK is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CAK?
The Hyundai DP086CAK is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions standard does the DP086CAK meet?
The Hyundai DP086CAK is certified to U.S. EPA Tier 3 emissions standards.
Is the Hyundai DP086CAK still in production?
Yes — the Hyundai DP086CAK is a current production model.
Is a datasheet available for the DP086CAK?
Yes — an official Hyundai datasheet for the Hyundai DP086CAK can be downloaded from this page.
