Hyundai
Hyundai DP086CCK
DP086 Series
Hyundai DP086CCK 7.5L 6-cylinder diesel engine for generator sets. EPA Tier 3 certified.
Chat on WhatsApp about this engine
Opens WhatsApp with Hyundai DP086CCK and this page link filled in.
- Manufacturer files
- 4 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 300 kVA
- Electrical Output
- 240 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 242.2 | 218 | 272.5 |
| Standby Power | 266.7 | 240 | 300 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 266.7 | 240 | 300 |
| Standby Power | 295.6 | 266 | 332.5 |
Hyundai DP086CCK generator set context
The Hyundai DP086CCK is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 300 kVA / 240 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CCK |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CCK?
The Hyundai DP086CCK is rated at 300 kVA standby / 273 kVA prime at 50 Hz (1,500 rpm); and 333 kVA standby / 300 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CCK run at 50 Hz or 60 Hz?
The Hyundai DP086CCK is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CCK use?
The Hyundai DP086CCK is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CCK?
The Hyundai DP086CCK is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions standard does the DP086CCK meet?
The Hyundai DP086CCK is certified to U.S. EPA Tier 3 emissions standards.
Is the Hyundai DP086CCK still in production?
Yes — the Hyundai DP086CCK is a current production model.
Is a datasheet available for the DP086CCK?
Yes — an official Hyundai datasheet for the Hyundai DP086CCK can be downloaded from this page.
