Haifeng Machinery

Hyundai DP086CCV

Hyundai DP086CCV — 7.527-litre inline-6 diesel engine. Find specifications, documents and parts support below.

Production StatusIn Production

DX08

Representative Hyundai engine
Electrical output 50 Hz · 1500 RPM
Prime power202 kWe
Standby power223 kWe
Configuration
L6
Displacement
7.527 L
Fuel
Diesel

Power Ratings

kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf

50 Hz1500 RPM

RatingPrimeStandby
Mechanical power kWm223245
Electrical output kWe202223

60 Hz1800 RPM

RatingPrimeStandby
Mechanical power kWm259285
Electrical output kWe232256

Datasheet & documents

Match the model number on your engine plate to the document. Check its revision date and the speed and duty listed for each power rating.

Source notes

Hyundai DP086CCV, DX08 common-rail generator-drive engine, 7.527 L L6.

Updated from the user-supplied Hyundai / Power Solutions Limited lineup dated 2026-10-07.

The sheet lists Euro Stage V; this is a lineup declaration, not an independently checked model-year certification certificate.

Mechanical engine kW and reference genset electrical kWe are stored separately.

Ratings are rounded reference values; final ratings require the specific engine technical datasheet and genset output depends on alternator efficiency.

Unlisted frequency ratings and unsupported kVA are left blank.

View DP086CCV spec image
Shareable spec cardHyundai DP086CCV summary imageOpen image
Hyundai DP086CCV 7.527L L6 diesel generator engine — 279 kVA standby specifications

Technical specifications

Technical Specifications

BrandHyundai
ModelDP086CCV
SeriesDX08
ConfigurationL6
Cylinders6
Displacement7.527 L
Dry Weight939 kg
Fuel TypeDiesel
Ignition TypeCompression Ignition
Cooling MethodLiquid-Cooled
Emissions StandardEuro Stage V
Country of OriginSouth Korea

Check your engine model

The Hyundai DP086CCV is a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, rated at 279 kVA / 223 kWe / standby rating. Match the model and serial number on your engine plate when requesting a manual or parts. The ratings and emissions information below help identify the version fitted to your generator.

Other ways this model is written

dp086ccvHyundai DP086CCVDX08 DP086CCV

DP086CCV repair parts

Haifeng supplies overhaul parts, filters, fuel injection parts and engine controls. Send your engine plate and the parts you need for a parts and delivery quote.

Get a parts & air-shipping quote
In-stock parts: same-day dispatch

Worldwide air shipping. Tell us your city and country for a shipping quote and estimated arrival date.

Find the right part

Send your engine plate, part numbers or photos, quantity, and delivery city. Parts can differ between versions of the same engine.

Which parts do you need?

Other parts? Add them in the chat.

Get my parts quote on WhatsApp

We’ll confirm the correct parts, stock and delivery cost before you order.

Opens WhatsApp. Attach photos in the chat.

Photos and details to send
  1. Take a clear photo of the engine nameplate.
  2. Tell us what needs repair or replacement.
  3. Send both in WhatsApp to start a fitment check.
How to read your engine nameplate

These categories have model-related records. Part numbers need further checking before we display them here.

Get help with this engine

Need a manual, a replacement part or help with an engine problem? Tell us what happened and include the serial number if you have it.

Opens WhatsApp. You can edit your message before sending.

Other ways to contact us
Scan QRHide QRHaifeng general WhatsApp chat QR codeGeneral WhatsApp chatScan with your phone. Add the model and your request in chat.Haifeng sales team

Need help after checking the documents?

Send us the part number or describe the problem. This engine model is included in your message.

Send this model enquiry by email

Or browse Haifeng's diesel generator sets

Frequently asked questions

What is the power output of the Hyundai DP086CCV?

The Hyundai DP086CCV is rated at 279 kVA standby / 253 kVA prime at 50 Hz (1,500 rpm); and 320 kVA standby / 290 kVA prime at 60 Hz (1,800 rpm).

Does the DP086CCV run at 50 Hz or 60 Hz?

The Hyundai DP086CCV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).

What fuel does the Hyundai DP086CCV use?

The Hyundai DP086CCV is a diesel generator-set engine.

What is the displacement and cylinder configuration of the DP086CCV?

The Hyundai DP086CCV is an inline-6 (6-cylinder) engine with a displacement of 7.527 L.

What emissions information is listed for the DP086CCV?

This record lists Euro Stage V for the Hyundai DP086CCV. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.

What is the catalog status of the Hyundai DP086CCV?

The Hyundai DP086CCV is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.

Are reference documents available for the DP086CCV?

This page links reference documents for the Hyundai DP086CCV. Check each document's title, model coverage, revision and rating conditions before using it for selection.
