Hyundai
Hyundai DP086CBV
DP086 Series
Hyundai DP086CBV 7.5L 6-cylinder diesel engine for generator sets. Euro Stage V certified.
- Standby Power · 50 Hz
- 256 kVA
- Electrical Output
- 205 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 206.7 | 186 | 232.5 |
| Standby Power | 227.8 | 205 | 256.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 234.4 | 211 | 263.8 |
| Standby Power | 260 | 234 | 292.5 |
Technical Specifications
| Brand | Hyundai |
| Model | DP086CBV |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | Euro Stage V |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CBV?
The Hyundai DP086CBV is rated at 256 kVA standby / 233 kVA prime at 50 Hz (1,500 rpm); and 293 kVA standby / 264 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CBV run at 50 Hz or 60 Hz?
The Hyundai DP086CBV is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CBV use?
The Hyundai DP086CBV is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CBV?
The Hyundai DP086CBV is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions standard does the DP086CBV meet?
The Hyundai DP086CBV is certified to Euro Stage V emissions standards.
Is the Hyundai DP086CBV still in production?
Yes — the Hyundai DP086CBV is a current production model.
Is a datasheet available for the DP086CBV?
Yes — an official Hyundai datasheet for the Hyundai DP086CBV can be downloaded from this page.
