Hyundai
Hyundai DP086CBK
DP086 Series
Hyundai DP086CBK 7.5L 6-cylinder diesel engine for generator sets. EPA Tier 3 certified.
Overhaul & repair parts- Supporting documents
- 4 documents · 2 datasheets
- Last updated
- 2026-05-29
- Package route
- diesel generator sets
- Standby Power · 50 Hz
- 256 kVA
- Electrical Output
- 205 kWe
- Cylinders
- L6
- Displacement
- 7.5 L
- Rated Speed
- 1,500 / 1,800 RPM
Power Ratings
kWm = mechanical shaft power · kWe = electrical output · kVA = kWe ÷ 0.8 pf
50 Hz1500 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 206.7 | 186 | 232.5 |
| Standby Power | 227.8 | 205 | 256.3 |
60 Hz1800 RPM
| kWm | kWe | kVA | |
|---|---|---|---|
| Prime Power | 234.4 | 211 | 263.8 |
| Standby Power | 260 | 234 | 292.5 |
Ask about Hyundai DP086CBK
Choose parts / service or sourcing. Your message includes this model and page link.
Hyundai DP086CBK overhaul & repair parts
Already running a Hyundai DP086CBK? Start with the parts you need, then send your nameplate so we can help check the right references for your engine.
These categories have model-related records. Part numbers need further checking before we display them here.
Let’s identify the right parts.
The model is the starting point. Serial numbers and build configurations can change which parts fit.
- Take a clear photo of the engine nameplate.
- Tell us what needs repair or replacement.
- Send both in WhatsApp to start a fitment check.
Opens WhatsApp with DP086CBK and your selected categories included. Attach your photos there.
Hyundai DP086CBK generator set context
The Hyundai DP086CBK is listed here as a diesel generator-drive engine for 50 Hz and 60 Hz generator sets, with a headline 256 kVA / 205 kWe / standby rating. Use this page to compare the published engine output, electrical kWe/kVA ratings, emissions level, datasheet availability, and neighboring models before specifying an alternator, controller, enclosure, voltage, and compliance package.
Also searched as
Technical Specifications
| Brand | Hyundai |
| Model | DP086CBK |
| Series | DP086 Series |
| Configuration | L6 |
| Cylinders | 6 |
| Displacement | 7.5 L |
| Fuel Type | Diesel |
| Ignition Type | Compression Ignition |
| Cooling Method | Liquid-Cooled |
| Emissions Standard | U.S. EPA Tier 3 |
| Country of Origin | South Korea |
Frequently asked questions
What is the power output of the Hyundai DP086CBK?
The Hyundai DP086CBK is rated at 256 kVA standby / 233 kVA prime at 50 Hz (1,500 rpm); and 293 kVA standby / 264 kVA prime at 60 Hz (1,800 rpm).
Does the DP086CBK run at 50 Hz or 60 Hz?
The Hyundai DP086CBK is available for both 50 Hz (1,500 rpm) and 60 Hz (1,800 rpm).
What fuel does the Hyundai DP086CBK use?
The Hyundai DP086CBK is a diesel generator-set engine.
What is the displacement and cylinder configuration of the DP086CBK?
The Hyundai DP086CBK is an inline-6 (6-cylinder) engine with a displacement of 7.5 L.
What emissions information is listed for the DP086CBK?
This record lists U.S. EPA Tier 3 for the Hyundai DP086CBK. Confirm the exact engine family, model year, configuration and applicable manufacturer certification documents before specifying it for a regulated project. A database label does not establish certification of a complete generator package.
What is the catalog status of the Hyundai DP086CBK?
The Hyundai DP086CBK is marked active in this database. Confirm current production and availability with the manufacturer; catalog status is not a live supply check.
Are reference documents available for the DP086CBK?
This page links reference documents for the Hyundai DP086CBK. Check each document's title, model coverage, revision and rating conditions before using it for selection.
